Airtac 6HV Manifold Solenoid Valve 6HV0500M21F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M21F Manifold-Mounted Solenoid Valve Specifications
- Model: 6HV0500M21F
- Type: 5/2-way monostable (single solenoid) with manual override
- Port size: 1/4" NPT (G1/8 optional)
- Operating pressure: 0.1–1.0 MPa (14.5–145 PSI)
- Vacuum capability: -0.1 to 1.0 MPa
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Power consumption: 1.6W (DC), 3.5VA (AC)
- Response time: ≤15ms (open/close at rated voltage)
- Flow coefficient (Cv): 0.5 (at 7 bar)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Valve body material: Reinforced PBT with UL94 V-0 flame rating
- Temperature range: -5℃ to 60℃ (with silicone seals: -20℃ to 80℃)
- Protection rating: IP67 (dustproof and waterproof immersion up to 1m)
- Weight: 320g ±5% (excluding manifold base)
- Dimensions: 56mm(L) × 25mm(W) × 42mm(H) (single valve module)
- Manifold compatibility: Up to 20 valves in series configuration
- Port thread depth: 9mm (minimum engagement recommended)
High-density modular valve designed for centralized pneumatic control systems requiring multi-valve configurations. Features zero-pressure differential activation and shock-resistant coil design. The integrated LED status indicator provides visual operation feedback. Requires ISO 8573-1:2010 Class 3 compressed air (max 5mg/m³ oil content).
- Automated assembly line clamping/unclamping systems
- Multi-axis robotic end effector controls
- Beverage filling machine actuator clusters
- Plastic injection molding machine core pulls
- Semiconductor wafer handling vacuum/pressure switching
Installation protocol:
Mount on ISO 5599/1 compliant manifold base with 0.5-0.6Nm tightening torque.
Maintain horizontal manifold orientation for optimal condensate drainage.
Use shielded cables for EMI protection in high-density installations.
| Property | Property Value |
|---|---|
| sku | 6HV0500M21F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
