Airtac 6HV Manifold Solenoid Valve 6HV0500M24F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M24F Manifold-Mounted Solenoid Valve Specifications
- Model: 6HV0500M24F
- Type: 5/2-way double solenoid, normally closed (manifold series)
- Port size: 1/4" NPT (G1/4 optional)
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Voltage: DC24V ±10% (coil class F insulation)
- Power consumption: 1.8W (steady state)/22VA (inrush)
- Response time: ≤15ms (at 0.5MPa)
- Flow capacity: CV 1.8 (Kv 1.56)
- Weight: 500g ±3% (excluding manifold base)
- Dimensions: 60mm(L) × 35mm(W) × 75mm(H) (single valve body)
- Seal material: NBR/FKM (optional Viton for high temp)
- Temperature range: -5℃ to 60℃ (NBR)/0℃ to 80℃ (FKM)
- Protection rating: IP65 (coil)/IP40 (valve body)
- Port alignment: ISO 5599-1 standard
- Manual override: Built-in push button (optional locking type)
High-density manifold valve designed for multi-valve centralized control systems. Features anti-vibration structure with copper-free aluminum alloy body and SUS304 piston. The low-power dual coil design enables pulse operation with 100% ED rating. Includes LED status indicator and surge protection circuit. Requires 5μm filtered lubricated air (ISO 8573-1 class 4).
- Multi-station pneumatic fixture control in CNC machining
- Bottle cap sorting & capping machine sequencing
- Automotive welding robot tool changers
- Plastic injection molding machine core-pull systems
- Semiconductor wafer handling equipment
Installation note:
Maximum 10 valves can be manifold-mounted in series. Apply Loctite 542 on port threads.
Maintain 0.3MPa minimum pilot pressure for stable operation. Allow 15mm clearance below
manifold for tubing connections.
| Property | Property Value |
|---|---|
| sku | 6HV0500M24F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
