Airtac 6HV Manifold Solenoid Valve 6HV0500M4F
2. Internal exhaust structure collects and centrally exhausts pilot air through R/S ports;
3. Body constructed from extruded aluminum alloy with specialized machining on internal passages to maximize flow area and enhance valve flow rate;
4. Snap-fit DIN rail mounting enables flexible modular valve group integration with quick assembly/disassembly and convenient maintenance.
Categories: Solenoid Valves, Brand: Airtac, Series: 6HV
AirTAC 6HV0500M4F Manifold Solenoid Valve Specifications
- Model: 6HV0500M4F
- Type: 5/2-way manifold solenoid valve (double solenoid)
- Port size: G1/8 (ISO228/1 standard)
- Operating pressure range: 0.15–1.0 MPa
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Max flow rate: 650 L/min (ANR, at 0.5MPa)
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Weight: 1.8 kg (including manifold base)
- Dimensions: 120mm(L) × 40mm(W) × 80mm(H) (single valve stack)
- Seal material: Heat-resistant NBR (Nitrile) up to 80℃
- Temperature range: -5℃ to 80℃ (non-freezing)
- Protection rating: IP67 (dustproof & waterproof)
- Electrical connection: DIN43650 Form A connector
- Manual override: Built-in push-button operation
- Cycle life: ≥10 million operations
Modular manifold valve designed for centralized pneumatic control systems. Features aluminum alloy body with hard anodized finish for corrosion resistance. The stacked design allows multiple valves to share common air supply/exhaust ports, significantly reducing piping complexity. Includes LED status indicators and surge protection circuitry.
- Automated assembly line actuator clusters
- Textile machinery multi-cylinder control
- Plastic injection molding machine sequences
- Semiconductor handling equipment
- Automotive tire assembly systems
Installation note:
Maximum recommended stacking: 12 valves per manifold. Maintain 50mm clearance above valve for heat dissipation. Use AirTAC SMC-04 grease for lubrication in high-cycle applications (>5Hz switching).
| Property | Property Value |
|---|---|
| sku | 6HV0500M4F |
| Port Size | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
| Standard Voltage | Please provide the specific AirTAC product attribute values you need translated, and I will return the accurate English terminology. |
