Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA1007-1
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ Adjustable Self-Compensating Hydraulic Shock Absorber ACA1007-1 Specifications
- Model: ACA1007-1
- Type: Auto-compensating oil hydraulic buffer
- Max. energy absorption: 1.3 Nm/cycle
- Impact speed range: 0.3–1.5 m/s
- Shaft diameter: Ø10 mm (h7 tolerance)
- Stroke length: 17 mm
- Operating temperature: -10℃ to +80℃
- Housing material: Nickel-plated steel
- Piston rod material: Stainless steel (SUS304)
- Seal material: NBR + VITON hybrid
- Weight: ~450g (with standard accessories)
- Dimensions: 65mm(L) × 25mm(W) × 25mm(H)
- Mounting torque: 15–20 Nm
- Oil capacity: 8.5 cm³
- Adjustment range: 5–100% damping force via 24-position rotary knob
Precision-engineered hydraulic damper with automatic viscosity compensation, maintaining consistent braking performance across temperature variations. Features dual-stage sealing system with contamination-resistant wiper ring. Includes anti-rotation lock nut and hexagonal mounting surfaces for tool-assisted installation.
- High-cycle automation equipment (3,000+ operations/day)
- Cartesian robot end effector stabilization
- Packaging machine gripper positioning
- CNC tool changer impact absorption
- Elevator car emergency braking systems
Installation note:
Align buffer axis within 0.5° of impact direction. Perform 20–30 test strokes
after oil filling before final adjustment. Re-torque mounting bolts after
48 hours of operation.
| Property | Property Value |
|---|---|
| sku | ACA1007-1 |
| External Thread | M10 |
| Stroke | 7mm |
| Bumper Cap Code | Plastic Bumper Cap |
