Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA1007-2
$26.59
Regular price
$34.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACA1007-2
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACJ Adjustable Self-Compensating Hydraulic Shock Absorber
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
Installation note:
Mount with 0.5-1mm clearance between rod end and impact surface. Perform initial adjustment at 50% load capacity (position 3), then fine-tune while observing movement. Allow 10-minute run-in period before final calibration.
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ Adjustable Self-Compensating Hydraulic Shock Absorber ACA1007-2 Specifications
- Model: ACA1007-2
- Type: Auto-compensating oil hydraulic buffer
- Max. impact energy: 35 J/cycle
- Max. impact velocity: 5 m/s
- Max. impact frequency: 180 cycles/min
- Max. load capacity: 1,500 N
- Stroke: 15 mm (adjustable)
- Adjustment mechanism: 6-position rotary dial (0-5)
- Operating temperature: -5℃ to 80℃
- Housing material: Aluminum alloy with hard anodizing
- Rod material: Chromium-plated steel
- Seal material: Nitrile rubber (NBR)
- Oil type: ISO VG32 hydraulic oil
- Mounting: Double-screw M10×1.25
- Weight: 0.85 kg
- Dimensions: 100mm(L) × 50mm(W) × 50mm(H)
Precision-engineered hydraulic damper featuring automatic viscosity compensation technology for consistent performance across temperature variations. The ACA1007-2's unique dual-chamber design minimizes oil foaming while its progressive damping curve ensures smooth deceleration. Includes dust-resistant wiper seal and maintenance-free operation for over 1 million cycles.
Typical Applications:
- High-speed pick-and-place robot end effectors
- Automated packaging line stopper mechanisms
- CNC machine tool door damping systems
- Elevator car counterweight guides
- Material handling conveyor impact zones
Installation note:
Mount with 0.5-1mm clearance between rod end and impact surface. Perform initial adjustment at 50% load capacity (position 3), then fine-tune while observing movement. Allow 10-minute run-in period before final calibration.
Maintenance Protocol:
- Check oil level every 6 months/50,000 cycles
- Rotate adjustment dial monthly to prevent seal hardening
- Inspect for rod scoring every 3 months
- Replace wiper seal at 2-year intervals
| Property | Property Value |
|---|---|
| sku | ACA1007-2 |
| External Thread | M10 |
| Stroke | 7mm |
| Bumper Cap Code | Plastic Bumper Cap |
