Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA2020-1
$45.20
Regular price
$52.70
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACA2020-1
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACJ Adjustable Self-Compensating Hydraulic Shock Absorber
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
Installation protocol:
Prime the buffer with 3-5 manual compressions before mounting.
Adjust damping force while monitoring the "green zone" indicator window - optimal setting achieved when yellow band remains visible during 90% of compression.
Perform torque check (18-22 N·m) on mounting nut every 2,000 operating hours.
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACA2020-1 Specifications
- Model: ACA2020-1
- Type: Multi-stage adjustable oil hydraulic buffer with automatic wear compensation
- Max. absorbed energy: 7.5 N·m/cycle
- Max. impact velocity: 2.5 m/s
- Stroke length: 20 mm
- Adjustment range: 5-100% damping force via 24-position rotary knob
- Max. impact force: 1,800 N
- Operating temperature: -10℃ to +80℃
- Oil type: ISO VG 32 hydraulic oil (pre-filled)
- Mounting orientation: Horizontal or vertical (±5° tolerance)
- Weight: 480 g ±2%
- Dimensions: 62mm (Body Ø) × 102mm (Total length)
- Mounting dimensions: M20×1.5 thread, 30mm engagement depth
- Housing material: Chrome-plated steel with PTFE-coated piston rod
- Replacement cycle: 500,000 operations (under rated load)
Precision-engineered hydraulic damper featuring automatic stroke compensation that maintains consistent braking performance despite seal wear or temperature fluctuations. The dual-chamber design separates oil reservoir from working chamber for stable viscosity control. Includes built-in debris exclusion wiper and 360° adjustable mounting collar.
Typical Applications:
- High-cycle CNC turret punch press ram deceleration
- Robotic arm end effector impact absorption
- Automated warehouse vertical lift positioning
- Die casting machine ejector systems
- Packaging line product stacking mechanisms
Installation protocol:
Prime the buffer with 3-5 manual compressions before mounting.
Adjust damping force while monitoring the "green zone" indicator window - optimal setting achieved when yellow band remains visible during 90% of compression.
Perform torque check (18-22 N·m) on mounting nut every 2,000 operating hours.
| Property | Property Value |
|---|---|
| sku | ACA2020-1 |
| External Thread | M20 |
| Stroke | <20mm> |
| Bumper Cap Code | Plastic Bumper Cap |
