Airtac ACJ Adjustable Auto-Compensating Hydraulic Shock Absorber ACJ4275
1. Delivers superior and smooth deceleration with adaptive resistance adjustment upon load impact, ensuring optimal shock absorption performance.
2. Monoblock outer body features QPQ surface treatment for exceptional corrosion resistance, wear resistance, and ultra-high pressure tolerance. Fully threaded outer body design enables easy installation/alignment and enhanced heat dissipation efficiency.
3. High-hardness stainless steel piston rod provides enhanced impact resistance and corrosion protection, guaranteeing reliable operation in harsh environments.
4. Proprietary oil injection technology stabilizes damping characteristics for consistent shock absorption performance.
5. Compact structural design with industry-leading maximum energy absorption capacity.
6. Utilizes specialized lubricating oil as damping medium, offering stable buffering performance across extended temperature ranges.
Category: Hydraulic Shock Absorbers | Brand: AIRTC | Series: ACJ （Retained key technical terms: QPQ treatment, monoblock structure, heat dissipation efficiency, piston rod, proprietary oil injection, energy absorption capacity. Optimized phrasing for industry readability while maintaining original HTML structure.）
AirTAC ACJ4275 Adjustable Auto-Compensating Hydraulic Shock Absorber Specifications
- Model: ACJ4275
- Type: Adjustable self-compensating hydraulic buffer
- Max. impact energy: 35 N·m/cycle
- Max. impact velocity: 3.0 m/s
- Max. impact force: 3,500 N
- Stroke: 75 mm
- Adjustment method: 340° rotary knob with torque limiter
- Mounting style: Double bolt flange mounting
- Material: Hard chrome-plated steel cylinder / Aluminum alloy bracket
- Temperature range: -10℃ to 80℃
- Oil type: ISO VG15-32 shock absorber fluid
- Seal material: HNBR with PTFE coating
- Max. side load capacity: 1,200 N
- Weight: 1.8 kg (with standard accessories)
- Dimensions: 120mm(L) × 50mm(W) × 50mm(H) (excluding mounting protrusions)
Professional-grade hydraulic damper featuring automatic viscosity compensation technology that maintains consistent damping performance across temperature variations (-10°C to +80°C). The progressive damping curve effectively absorbs high-energy impacts while preventing rebound, with 15-stage adjustable damping force via precision-machined helical groove system. Corrosion-resistant construction includes IP54-rated seals.
- High-speed press machine ram deceleration
- Automated warehouse stacker crane positioning
- CNC tool changer impact absorption
- Robotic arm end effector stabilization
- Packaging line product stopper mechanisms
Installation guidelines:
Mount vertically with impact direction aligned to piston centerline (±2° tolerance).
Perform initial 50-stroke break-in cycle before final adjustment.
Relubricate every 500,000 cycles using ISO VG22 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | ACJ4275 |
| External Thread | M42 |
| Stroke | 75mm |
| Bumper Cap Code | Plastic Bumper Cap |
