Airtac AFC Combination Unit AFC2000L1
2、Integrated self-locking mechanism prevents undesired pressure setting adjustments from external interference;
3、Minimal pressure drop with high drainage efficiency;
4、Transparent sight glass enables visual monitoring of lubricant drip rate;
5、Available in standard configuration or low-pressure variant (maximum adjustable pressure 0.4MPa).
Category: FRL Combination Units , Brand: Airtac , Series: AFC
AirTAC AFC2000L1 Filter Regulator Lubricator (FRL) Unit Specifications
- Model: AFC2000L1
- Type: Compact 2-stage combination unit (Filter + Regulator)
- Port size: PT1/2" (G1/2 optional)
- Operating pressure range: 0.05–1.0 MPa
- Max flow rate: 3,500 L/min (ANR)
- Filter element: 5μm (40μm optional)
- Water trap efficiency: ≥80% at 0.7MPa
- Pressure gauge range: 0–1.6 MPa (Bourdon tube type)
- Body material: Die-cast aluminum (anodized)
- Seal material: NBR/HNBR
- Temperature range: 5℃ to 60℃ (non-freezing)
- Weight: 1.8 kg (dry)
- Dimensions: 190mm(W) × 155mm(H) × 85mm(D)
- Mounting: Panel bracket or rail mount
- Pressure adjustment knob: Lockable rotary type
Modular FRL unit combining 5μm particulate filtration with precision pressure regulation. Features automatic drainage with manual purge, visible bowl contamination indicator, and shock-resistant polycarbonate bowl. Designed for industrial environments requiring stable air preparation with minimal pressure drop.
- Production line pneumatic tool stations
- CNC machine air preparation systems
- Automated assembly line actuators
- Packaging machinery air circuits
- Robotic arm pneumatic controls
- Plastic injection molding machines
Maintenance protocol:
Replace filter element every 6,000 operating hours or when pressure drop exceeds 0.1MPa.
Drain bowl daily in high-humidity environments. Use vertical installation (±15° tolerance)
for optimal drainage performance.
| Property | Property Value |
|---|---|
| sku | AFC2000L1 |
| Port Size | PT1/4 |
