AirTAC AR150-04 AR1500/2000 Pressure Regulator (AR15004)
1. Features compact and lightweight design for simplified installation and operation;
2. Integrated press-in self-locking mechanism prevents unintended pressure setting changes due to external disturbances;
3. Optional low-pressure variant available (maximum adjustable pressure 0.4MPa) in addition to standard configuration.
Category: Pressure Regulator | Brand: AIRTAC | Series: AR1500/2000
AirTAC AR1500/2000 Series Pressure Regulator AR15004 Technical Details
- Model: AR15004 (AR1500/2000 series)
- Type: Precision pressure regulator with gauge port
- Port size: PT1/4 (BSPP thread standard)
- Operating pressure range: 0.05–0.85 MPa
- Maximum pressure: 1.0 MPa
- Flow capacity: 3,500 Nl/min (ANR)
- Accuracy: ±0.08 MPa
- Ambient temperature range: -5℃ to 60℃
- Weight: 0.5 kg (with gauge)
- Dimensions: 120mm(L) × 60mm(W) × 85mm(H)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR rubber (oil & heat resistant)
- Mounting options: Panel mount or inline installation
- Gauge compatibility: 1/8" BSP pressure gauge port
- Filter element: 40μm sintered bronze (replaceable)
High-precision pressure regulator with integrated locking mechanism and tamper-proof adjustment knob. Features dual-chamber design for stable output under fluctuating input pressures. The built-in relief function prevents over-pressurization, while the clear scale (0.01 MPa graduations) enables precise pressure tuning. Compatible with ISO 8573-1:2010 Class 4 compressed air.
- Production line pneumatic tool pressure stabilization
- CNC machine air pressure compensation systems
- Plastic injection molding machine air circuits
- Semiconductor manufacturing equipment
- Automated packaging machinery pressure control
- Industrial robot end-effector pneumatic systems
Maintenance protocol:
Drain condensate weekly via bottom port. Replace filter element every
2,000 operating hours. Use PTFE tape on threaded connections - do not
overtighten (max 1.5 N·m torque). Align flow arrow with system direction.
| Property | Property Value |
|---|---|
| sku | AR15004 |
| Port Size | PT1/8 |
