Airtac CPV10M Mounting Base CPV10MJ03-11F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-11F Mounting Base Specifications
- Model: CPV10MJ03-11F
- Compatible Series: CPV10M miniature cylinders
- Material: Aluminum alloy (6063-T5)
- Surface treatment: Anodized (natural silver finish)
- Mounting type: Side-mount with dual rail slots
- Mounting hole spacing: 10mm ±0.2 (M5 screw compatibility)
- Load capacity: Max 15kg vertical static load
- Vibration resistance: ≤20 m/s² (ISO 10816-3 compliant)
- Weight: 185g ±5g
- Dimensions: 50mm(L) × 30mm(W) × 20mm(H)
- Operating temperature: -20℃ to 80℃
- Surface hardness: HV 80-100
- Corrosion resistance: 96hr salt spray test passed
Precision-engineered mounting base featuring anti-vibration grooves and thermal expansion compensation slots. The diamond-cut machining ensures ±0.05mm positional accuracy for cylinder alignment. Includes integrated cable management channels and corrosion-resistant coating for harsh environments.
- Robotic arm joint stabilization
- PCB assembly line positioning systems
- Pharmaceutical packaging machinery
- Automated optical inspection (AOI) equipment
- Cleanroom compatible medical devices
Installation note:
Use M5×0.8 screws with 0.5-0.6Nm torque. Apply thread-locking compound
for high-vibration environments. Maintain 0.1mm clearance between
mating surfaces for thermal expansion.
- CPV10M-10~50 cylinders
- MDBT10M magnetic sensors
- ASV10M series shock absorbers
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-11F |
