Airtac CPV10M Mounting Base CPV10MJ03-13F
$34.18
Regular price
$41.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ03-13F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation Guidelines:
Use M3×8mm flat-head screws (recommended torque 0.6N·m).
Apply thread-locking compound on fasteners in high-vibration environments.
Maintain 0.1-0.3mm clearance between cylinder body and bracket during installation.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-13F Cylinder Base Bracket Technical Details
- Model: CPV10MJ03-13F
- Compatible Series: CPV10M miniature cylinders
- Material: 6063-T5 aluminum alloy
- Surface Treatment: Black anodized (MIL-A-8625 Type II)
- Mounting Hole Spacing: 13mm (center-to-center)
- Thread Specifications: M3×0.5 mounting screws (4 places)
- Load Capacity: Max 25N lateral force
- Operating Temperature: -20°C to 100°C
- Pressure Resistance: ≤1.0 MPa system pressure
- Weight: 98g ±2g
- Dimensions: 42mm(L) × 28mm(W) × 12.5mm(H)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
Precision-machined mounting base designed for CPV10M series compact cylinders, featuring anti-corrosion coating and CNC-milled alignment grooves. Includes integrated shock-absorbing pads for reduced operational noise. Compatible with ISO 21287 standard cylinder footprints.
Primary Applications:
- Robotic end-effector tooling mounts
- Semiconductor wafer handling systems
- Pharmaceutical blister packaging machines
- Precision optical lens positioning stages
- Desktop automation test equipment
Installation Guidelines:
Use M3×8mm flat-head screws (recommended torque 0.6N·m).
Apply thread-locking compound on fasteners in high-vibration environments.
Maintain 0.1-0.3mm clearance between cylinder body and bracket during installation.
Service Life:
500,000 cycles under standard load conditions.
Clean mounting surface with isopropyl alcohol every 2,000 operating hours.
