Airtac CPV10M Mounting Base CPV10MJ03-14F
$36.05
Regular price
$43.55
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ03-14F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation protocol:
Apply 4.5-5.5 N·m torque during M5 screw fastening. Use shim washers
when mounting on uneven surfaces (>0.2mm deviation). Lubricate guide
slots before cylinder insertion.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-14F Cylinder Mounting Bracket Specifications
- Model: CPV10MJ03-14F
- Compatible Series: CPV10M Standard Cylinders
- Material: Aluminum alloy (anodized surface treatment)
- Mounting Type: Foot-mounted with reinforced ribs
- Bolt Hole Size: M5×0.8 (4 holes)
- Weight: 327g ±5g
- Dimensions: 104mm(L) × 40mm(W) × 20mm(H)
- Surface Hardness: HV 120-150
- Operating Temperature: -20℃ to 80℃
- Vibration Resistance: ≤10 m/s² (ISO 10816-3)
- Corrosion Protection: Chromate conversion coating
Heavy-duty mounting bracket engineered for secure CPV10M cylinder fixation in high-moment applications. Features precision-machined locating surfaces (flatness ≤0.1mm) and anti-loosening thread design. Includes integrated cable management grooves for pneumatic line routing.
Typical Applications:
- Robotic welding fixture positioning systems
- CNC machine tool clamping mechanisms
- Automated conveyor sorting arms
- Packaging machine vertical lift units
- Semiconductor handling equipment
Installation protocol:
Apply 4.5-5.5 N·m torque during M5 screw fastening. Use shim washers
when mounting on uneven surfaces (>0.2mm deviation). Lubricate guide
slots before cylinder insertion.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-14F |
