Airtac CPV10M Mounting Base CPV10MJ03-16F
$40.23
Regular price
$47.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ03-16F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation note:
Apply thread-locking compound (medium strength) to mounting screws.
Use 0.05mm feeler gauge to verify base-surface contact before final tightening.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-16F Mounting Base Specifications
- Model: CPV10MJ03-16F
- Compatibility: Designed for CPV10M series cylinders
- Material: Aluminum alloy (AL6063-T5)
- Surface treatment: Anodized (natural color)
- Mounting hole pattern: 32mm pitch (horizontal)
- Thread specification: M4×0.7 (4 mounting holes)
- Weight: 0.25kg ±5%
- Dimensions: 40mm(W) × 60mm(L) × 16mm(H)
- Operating temperature: -20℃ to 80℃
- Surface flatness: ≤0.1mm
- Corrosion resistance: 96hrs salt spray test passed
- Mounting torque: 1.2N·m max
Precision-machined mounting base with anti-vibration design, featuring diamond-knurled surface for enhanced grip during installation. Includes integrated alignment pins (Ø4h7) for accurate cylinder positioning. Compatible with ISO 15552 standard profiles.
Typical Applications:
- Modular pneumatic system assemblies
- Linear actuator installations in robotics
- Conveyor system cylinder mounting
- Semiconductor handling equipment
- Multi-axis positioning stages
Installation note:
Apply thread-locking compound (medium strength) to mounting screws.
Use 0.05mm feeler gauge to verify base-surface contact before final tightening.
Configuration Tips:
- For vertical mounting: Use 2 bases per cylinder minimum
- Maximum cantilever load: 15N (dynamic), 30N (static)
- Pair with CPV10M-T01 brackets for angular adjustments
- Thermal expansion compensation gap: 0.3mm recommended at 60℃+
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-16F |
