Airtac CPV10M Mounting Base CPV10MJ03-17F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-17F Mounting Base Specifications
- Model: CPV10MJ03-17F
- Compatible Series: CPV10M Standard Cylinders
- Material: Aluminum alloy ADC12
- Surface Treatment: Black anodized oxidation
- Mounting Type: Side-mount (ISO 15552 compatible)
- Bolt Hole Pattern: 17mm pitch (M5 threaded)
- Weight: 320g ±5g
- Dimensions: 54mm(L) × 42mm(W) × 28mm(H)
- Operating Temperature: -20℃ to 100℃
- Max Lateral Load Capacity: 150N
- Vibration Resistance: ≤10Hz with 1.5mm amplitude
- Mounting Torque: 3.5-4.5N·m (M5 screws)
Precision-machined mounting base designed for secure CPV10M cylinder fixation in multi-axis configurations. Features anti-corrosion coating and standardized mounting patterns for modular assembly. Includes integrated cable management grooves and alignment pins for simplified maintenance.
- Multi-station robotic welding fixtures
- Automated conveyor sorting systems
- CNC machine tool clamping units
- Pharmaceutical packaging line actuators
- Semiconductor handling robotics
Installation note:
Apply thread-locking compound (medium strength) on mounting screws.
Ensure base surface flatness ≤0.1mm/m before installation.
Compatible with ISO 6432/15552 mounting accessories.
- Requires M5×12mm hex socket screws (not included)
- Optimal installation sequence: Torque screws in diagonal pattern
- Thermal expansion coefficient: 23.6×10⁻⁶/℃
- Surface hardness: HV 120-150
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-17F |
