Airtac CPV10M Mounting Base CPV10MJ03-18F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-18F Mounting Base Specifications
- Model: CPV10MJ03-18F
- Compatibility: Designed for CPV10M series cylinders
- Material: Aluminum alloy (A6063-T5)
- Surface treatment: Anodized oxidation (silver)
- Mounting hole spacing: 18±0.1mm (horizontal) × 30±0.15mm (vertical)
- Thread specifications: M4×0.7 mounting screws (4 places)
- Weight: 215±5g
- Dimensions: 102mm(L) × 48mm(W) × 18mm(H)
- Operating temperature: -20℃ to 80℃
- Surface hardness: HV 12° or higher
- Corrosion resistance: 96hr salt spray test compliant
- Mounting torque: 1.2-1.5N·m (recommended)
Precision-machined mounting base with dual D-shaped alignment slots for secure CPV10M cylinder fixation. Features vibration-damping design with 0.02mm flatness tolerance on mounting surface. Includes integrated cable routing channels and corrosion-resistant coating for industrial environments.
- Robotic arm joint actuators
- PCB assembly line positioning systems
- Automated packaging machinery
- Semiconductor handling equipment
- Precision optical stage controls
Installation note:
Apply thread-locking compound (medium strength) on screws and
torque in cross pattern sequence. Ensure cylinder rod axis remains
within ±0.5° perpendicularity to mounting surface.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-18F |
