Airtac CPV10M Mounting Base CPV10MJ03-19F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-19F Cylinder Mounting Base Specifications
- Model: CPV10MJ03-19F
- Compatibility: Designed for CPV10M series cylinders
- Material: High-strength aluminum alloy (AL6063-T5)
- Mounting type: Side/Bottom mounting with M4 threaded holes
- Port configuration: Dual M5 (G1/8" optional) pneumatic ports
- Surface treatment: Hard anodized (15-25μm thickness)
- Load capacity: Max 180N static load
- Temperature range: -20℃ to 100℃ (continuous operation)
- Weight: 248g ±5g
- Dimensions: 76mm(L) × 40mm(W) × 19mm(H)
- Mounting hole spacing: 60mm center-to-center
- Surface flatness: ≤0.05mm
- Corrosion resistance: 500hr salt spray test passed
Precision-engineered mounting base featuring dual-port flow optimization and vibration-damping design. The staggered port arrangement (19mm pitch) enables compact piping layouts while maintaining 95%+ flow efficiency. Includes integrated shock absorption pads and anti-loosening thread locks for high-cycle applications.
- Multi-axis pneumatic positioning systems
- PCB handling robots with space constraints
- Packaging machine vertical lift mechanisms
- Semiconductor wafer transfer modules
- Automated optical inspection (AOI) equipment
Installation protocol:
Use M4×12mm stainless steel screws (recommended torque 1.2N·m) with parallel
tightening sequence. Apply thread sealant on port connections. Allow 3mm
thermal expansion gap when operating above 60℃.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-19F |
