Airtac CPV10M Mounting Base CPV10MJ03-20F
$48.82
Regular price
$56.32
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ03-20F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation protocol:
Apply 0.3-0.5Nm torque during screw fastening. Use shim washers
when mounting on uneven surfaces exceeding 0.02mm flatness deviation.
Compatible with M4×8mm flat head screws (not included).
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-20F Mounting Base Specifications
- Model: CPV10MJ03-20F
- Compatible Series: CPV10M Cylinder Series
- Material: Anodized aluminum alloy (A6063-T5)
- Mounting Type: Side-mount fixed base
- Bore Size Compatibility: ø10mm cylinders
- Mounting Hole Pattern: 20mm center-to-center spacing
- Thread Specifications: M4×0.7 mounting screws (4 places)
- Surface Hardness: HV 80-100
- Weight: 185g ±5g
- Dimensions: 42mm(L) × 20mm(W) × 14.5mm(H)
- Operating Temperature: -20℃ to 120℃
- Surface Treatment: Black anodized (anti-abrasion coating)
- Vibration Resistance: ≤49 m/s² (10-150Hz)
Precision-engineered mounting base featuring laser-etched alignment marks for rapid installation. The diamond-knurled surface enhances grip during manual adjustments, while the through-hole design allows integrated sensor wiring. Compatible with ISO 6432 mounting standards.
Typical Applications:
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Linear guide parallel installation setups
- Semiconductor handling equipment
- Automated test fixture positioning
Installation protocol:
Apply 0.3-0.5Nm torque during screw fastening. Use shim washers
when mounting on uneven surfaces exceeding 0.02mm flatness deviation.
Compatible with M4×8mm flat head screws (not included).
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-20F |
