Airtac CPV10M Mounting Base CPV10MJ03-2F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-2F Mounting Base for CPV10M Series Specifications
- Model: CPV10MJ03-2F
- Compatible Cylinder Series: CPV10M
- Material: Aluminum alloy ADC12 (die-cast)
- Surface Treatment: Black anodized oxidation
- Mounting Hole Pattern: Dual M5 threaded holes (center distance 25mm)
- Mounting Screw Torque: 1.5 N·m max
- Load Capacity: Supports up to 5kg static load
- Weight: 0.25kg ±5%
- Dimensions: 50mm(L) × 30mm(W) × 20mm(H)
- Operating Temperature: -20℃ to 80℃
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Shock Resistance: 100m/s² (3 axes, 3 times each)
Durable mounting base designed for secure CPV10M cylinder fixation in multi-axis configurations. Features precision-machined locating pins (Ø10h7 tolerance) and anti-rotation grooves. Includes integrated cable management channels for sensor wiring. Compatible with ISO 15552 mounting standards.
- Modular pneumatic assembly systems
- Multi-station rotary index tables
- Robotic end-effector mounting platforms
- Precision alignment in semiconductor handling
- Packaging line conveyor diverters
Installation note:
Apply thread-locking compound (medium strength) to M5 fasteners.
Ensure base surface flatness ≤0.1mm before mounting.
Use alignment jig PN MJ03-ALIGN for multi-unit installations.
- CPV10M-10~50 cylinders
- CPV10MJ03-1F (single foot version)
- ASNU-05M proximity sensors
- MK10 series mounting brackets
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-2F |
