Airtac CPV10M Mounting Base CPV10MJ03-3F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-3F Mounting Base Specifications
- Model: CPV10MJ03-3F
- Compatible Series: CPV10M solenoid valves
- Material: Anodized aluminum alloy (black oxidation)
- Mounting Type: ISO G1/8 sub-base with 3-position modular design
- Port Thread: G1/8 (BSPP)
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -5℃ to 80℃
- Weight: 215g ±5g
- Dimensions: 60mm(L) × 40mm(W) × 28mm(H)
- Surface Roughness: Ra ≤3.2μm (sealing surfaces)
- Mounting Torque: 1.2-1.5 N·m (for M5 mounting screws)
- Seal Compatibility: Compatible with NBR/PU/Urethane seals
- Vibration Resistance: ≤10 Hz (5-2000 Hz frequency range)
Precision-engineered modular base for building multi-valve manifolds in compact pneumatic systems. Features staggered port alignment for simplified tubing routing and hexagonal recesses for tool-assisted alignment. Includes integrated O-ring grooves with pre-installed NBR seals (AS568-012 standard). Compatible with DIN rail mounting adapters (sold separately).
- Multi-valve control stations in packaging machinery
- Modular pneumatic logic circuits
- Automated assembly line manifolds
- Mobile equipment control panels
- Laboratory pneumatic test benches
Installation note:
Apply thread sealant (LOCTITE 5452 recommended) on port threads.
Tighten manifold stacking screws diagonally in 3 stages (30% → 70% → 100% torque)
to ensure even pressure distribution. Maintain 15mm clearance below base for tubing access.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-3F |
