Airtac CPV10M Mounting Base CPV10MJ03-4F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-4F Valve Base Specifications
- Model: CPV10MJ03-4F
- Compatible valve series: CPV10M solenoid valves
- Material: Aluminum alloy (surface anodized)
- Mounting type: Sub-base for manifold assembly
- Port configuration: 4 stations (4F)
- Port thread size: PT1/4 (NPT1/4 optional)
- Max operating pressure: 1.0 MPa
- Seal material: NBR (nitrile rubber)
- Temperature resistance: -20℃ to 80℃
- Weight: 280±5g
- Dimensions: 132mm(L) × 20mm(H) × 42mm(W)
- Surface finish: Hard anodized (black)
- Mounting hole spacing: 25mm center-to-center
- Protection rating: IP40 (when installed)
Modular base unit for creating compact pneumatic manifolds with CPV10M series valves. Features precision-machined air passages and integrated silencer pockets. The staggered port design allows high-density piping with 4 independent circuits. Compatible with ISO 15407-1 standard valve footprints.
- Multi-valve control stations in packaging machinery
- Automated assembly line clamping systems
- Textile machine pneumatic clusters
- Semiconductor handling equipment manifolds
- Parallel circuit pneumatic control panels
Installation note:
Use M4×12 mounting screws with 0.6-0.8Nm torque. Apply thread sealant on port connections.
Ensure manifold alignment within ±0.2mm tolerance during stack assembly. Clean air passages
with filtered air before valve installation.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-4F |
