Airtac CPV10M Mounting Base CPV10MJ03-5F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-5F Mounting Base Specifications
- Model: CPV10MJ03-5F
- Compatible Series: CPV10M miniature pneumatic cylinders
- Material: Aluminum alloy ADC12
- Surface Treatment: Anodized oxidation (black)
- Mounting Type: Side-mount panel installation
- Weight: 120g ±5%
- Dimensions: 50mm(L) × 25mm(W) × 15mm(H)
- Thread Specifications: M5×0.8 mounting holes (4 places)
- Temperature Range: -20℃ to 80℃
- Vibration Resistance: ≤49 m/s² (with proper fastening)
- Max Installation Torque: 1.5 N·m (for mounting screws)
- Compatible Accessories: CPV10M series cylinders, MMF series manifold blocks
Precision-engineered mounting base featuring anti-corrosion treatment and CNC-machined positioning grooves. The diamond-shaped hole pattern ensures vibration-resistant fixation, with integrated cable routing channels for clean pneumatic line management. Includes built-in shock-absorbing pads to minimize resonance transmission.
- Modular assembly in robotic end effectors
- Precision alignment for semiconductor wafer handling
- Multi-axis coordinate measuring machines
- Compact packaging line diverters
- Medical device actuation systems
Installation protocol:
Use JIS B1176-compliant M5 screws with spring washers.
Apply 2-3 N·m crisscross tightening sequence for optimal load distribution.
Maintain 0.05mm maximum gap between base and mounting surface.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-5F |
