Airtac CPV10M Mounting Base CPV10MJ03-6F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-6F Cylinder Mounting Bracket Specifications
- Model: CPV10MJ03-6F
- Compatibility: Designed for CPV10M series compact cylinders
- Material: Anodized aluminum alloy (AL6061-T6)
- Mounting type: Side-mount with multi-position adjustment
- Bore size compatibility: Ø10mm cylinders
- Mounting hole spacing: 30mm (±0.2mm tolerance)
- Thread specifications: M6×1.0 mounting screws (4 places)
- Surface hardness: HV 80-100
- Weight: 220g ±5g
- Dimensions: 48mm(L) × 34mm(W) × 18mm(H)
- Temperature range: -20℃ to 120℃ (static operation)
- Surface treatment: Black anodized (12-15μm thickness)
- Vibration resistance: ≤50m/s² (10-2000Hz)
Precision-engineered mounting base for compact pneumatic systems, featuring anti-corrosion treatment and reinforced load-bearing design. The hexagonal cavity structure ensures 360° rotational positioning capability while maintaining minimal footprint. Includes integrated shock-absorbing pads for noise reduction.
- Modular robotic end-effector assemblies
- Semiconductor wafer handling equipment
- Precision dispensing machine tooling
- Automated optical inspection (AOI) systems
- High-cycle packaging line actuators
Installation protocol:
Apply 0.5-0.8N·m torque during screw fastening. Use included shim washers
when mounting on uneven surfaces (>0.1mm flatness deviation). Avoid
metal-to-metal contact in corrosive environments.
| Property | Property Value |
|---|---|
| sku | CPV10MJ03-6F |
