Airtac CPV10M Mounting Base CPV10MJ03-9F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ03-9F Cylinder Base Bracket Technical Details
- Full model designation: CPV10MJ03-9F
- Compatible series: CPV10M standard cylinders
- Material: Aluminum alloy 6063-T5
- Surface treatment: Hard anodized (25-30μm thickness)
- Mounting type: Through-hole flange mounting
- Bolt hole pattern: 30mm × 18mm rectangular array
- Bolt size compatibility: M5×0.8 threaded holes (4 places)
- Weight: 220g ±5g
- Dimensions: 90mm(L) × 30mm(W) × 20mm(H)
- Operating temperature: -20℃ to 80℃
- Surface hardness: HV400 minimum
- Corrosion resistance: 96hrs salt spray test compliant
- Vibration resistance: 10-2000Hz, 10G acceleration
Precision-machined mounting base for CPV10M series cylinders, featuring anti-loosening rib design and wear-resistant coating. The staggered bolt pattern ensures stable load distribution during high-cycle operations (up to 5 million cycles). Includes integrated cable management slots for sensor wiring.
- Robotic welding arm position locking
- High-speed packaging line cylinder arrays
- Semiconductor handling equipment
- Automated test fixture mounting systems
- Food processing conveyor guides
Installation protocol:
Apply 7-10Nm torque during bolt tightening using cross-pattern sequence.
Use stainless steel shim washers when mounting on plated surfaces.
Lubricate contact surfaces with molybdenum disulfide grease for high-vibration environments.
