Airtac CPV10M Mounting Base CPV10MJ04-10F
$28.60
Regular price
$36.10
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ04-10F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation note:
Apply 0.3-0.5Nm torque during screw tightening. Use M4×8mm SHCS
(socket head cap screws) and Loctite 243 threadlocker for high-vibration environments.
Clean mounting surface with IPA before assembly.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-10F Cylinder Mounting Base Specifications
- Model: CPV10MJ04-10F
- Compatible Series: CPV10M Standard Cylinders
- Material: Aluminum alloy (A6063-T5)
- Surface Treatment: Anodized (natural color)
- Mounting Type: ISO 15552 standard side-mount
- Bore Size Compatibility: Φ10mm cylinders
- Mounting Hole Pattern: 20mm × 16mm (horizontal × vertical)
- Thread Specifications: M4×0.7 mounting screws (4 places)
- Weight: 48g ±2g
- Dimensions: 34mm(L) × 25mm(W) × 10mm(H)
- Operating Temperature: -20℃ to 80℃
- Surface Hardness: HV 80-100
- Vibration Resistance: ≤10-55Hz (1.5mm amplitude)
Precision-machined mounting base designed for secure CPV10M cylinder fixation in space-constrained applications. Features anti-corrosion anodization and CNC-milled alignment grooves for perfect piston rod centering. Includes integrated vibration dampening channels.
Typical Applications:
- Miniature automation workstations
- Semiconductor handling robots
- Precision dispensing systems
- Optical lens positioning mechanisms
- Laboratory test equipment jigs
Installation note:
Apply 0.3-0.5Nm torque during screw tightening. Use M4×8mm SHCS
(socket head cap screws) and Loctite 243 threadlocker for high-vibration environments.
Clean mounting surface with IPA before assembly.
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-10F |
