Airtac CPV10M Mounting Base CPV10MJ04-11F
$30.46
Regular price
$37.96
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ04-11F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation protocol:
Apply thread-locking compound to mounting screws and torque in cross pattern sequence.
Ensure cylinder rod axis remains within ±0.2mm perpendicularity tolerance relative to base plane.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-11F Mounting Base Specifications
- Model: CPV10MJ04-11F (Compatible with CPV10M series cylinders)
- Material: High-strength aluminum alloy (A6063-T5)
- Surface treatment: Anodized finish (natural color)
- Mounting hole spacing: 40mm × 32mm (horizontal × vertical)
- Thread specifications: M5×0.8 mounting screws (4 places)
- Weight: 0.28kg ±2%
- Dimensions: 84mm(L) × 40mm(W) × 22mm(H)
- Operating temperature: -20℃ to 80℃
- Surface hardness: HV 80-100
- Corrosion resistance: 96hr salt spray test compliant
- Mounting torque: 2.0-2.5N·m (recommended for M5 screws)
Precision-engineered mounting base designed for secure CPV10M cylinder fixation in industrial automation systems. Features diamond-knurled anti-slip surface and through-hole design for simplified alignment. Compatible with ISO 15552 mounting standards.
Typical Applications:
- Linear actuator installations in packaging machinery
- Pneumatic clamping systems for CNC fixtures
- Material handling robot end-effector mounts
- Automated assembly line positioning units
- Laboratory equipment motion control systems
Installation protocol:
Apply thread-locking compound to mounting screws and torque in cross pattern sequence.
Ensure cylinder rod axis remains within ±0.2mm perpendicularity tolerance relative to base plane.
Cross-Reference:
Interchangeable with SMC MFH-10-□-Z and Festool EFM-10-□ bases when using adapter shims (0.1mm thickness recommended).
