Airtac CPV10M Mounting Base CPV10MJ04-12F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-12F Base Bracket for CPV10M Series
- Model: CPV10MJ04-12F
- Compatible Cylinder Series: CPV10M (10mm bore)
- Material: Aluminum alloy (anodized surface treatment)
- Mounting Type: Through-hole base bracket
- Hole Spacing: 12mm center-to-center (4 mounting holes)
- Thread Size: M3 mounting screws
- Surface Hardness: HV 80-100
- Weight: 98g ±2g
- Dimensions: 42mm(L) × 32mm(W) × 14mm(H)
- Operating Temperature: -20℃ to 100℃
- Surface Finish: Black oxidation resistant coating
- Parallelism Tolerance: ≤0.05mm
- Vibration Resistance: 10-55Hz (1.5mm amplitude)
Precision-machined mounting base designed for CPV10M compact cylinders, featuring reinforced rib structure for enhanced stability. The diamond-shaped groove design allows flexible orientation adjustment during installation. Includes integrated cable management channels for pneumatic tubing organization.
- Modular automation equipment assembly
- SCARA robot end-effector mounting
- Semiconductor wafer handling systems
- Precision dispensing machine fixtures
- Medical device actuator installations
Installation note:
Apply 0.2-0.3Nm torque during screw tightening. Use M3×8mm stainless steel screws
(not included). Align with cylinder mounting bosses before securing. For vertical
installations, apply thread-locking compound to prevent vibration loosening.
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-12F |
