Airtac CPV10M Mounting Base CPV10MJ04-13F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-13F Mounting Base for CPV10M Cylinder
- Model: CPV10MJ04-13F
- Type: Compact cylinder mounting base
- Material: High-strength aluminum alloy (A6063-T5)
- Compatible Cylinder Series: CPV10M series (10mm bore)
- Mounting Hole Spacing: 13mm (center-to-center)
- Thread Specifications: M4×0.7 mounting screws (4 places)
- Surface Treatment: Black anodized oxidation
- Weight: 28g ±2g
- Dimensions: 40mm(L) × 13mm(W) × 10mm(H)
- Operating Temperature: -20℃ to 80℃
- Lateral Load Capacity: ≤15N
- Vibration Resistance: 10-55Hz (1.5mm double amplitude)
Precision-machined mounting base designed for secure fixation of CPV10M miniature cylinders in space-constrained applications. Features anti-corrosion coating and laser-etched alignment marks for simplified installation. Includes integrated cable routing channels for clean pneumatic line management.
- PCB handling robots in electronics assembly
- Micro-pneumatic gripper systems
- Laboratory sample sorting mechanisms
- Semiconductor wafer processing equipment
- Precision dosing valve actuators
Installation note:
Apply 0.3-0.5N·m torque during screw tightening. Use M4 spring washers
to prevent loosening in high-vibration environments. Align base markings
with cylinder's air port orientation for optimal tubing routing.
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-13F |
