Airtac CPV10M Mounting Base CPV10MJ04-15F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-15F Cylinder Mounting Bracket Specifications
- Model: CPV10MJ04-15F
- Type: Compact cylinder mounting base (Side-mount)
- Compatible Series: CPV10M standard cylinders
- Material: Aluminum alloy (A6063-T5)
- Surface Treatment: Anodized (Natural silver)
- Bore Size Compatibility: Φ10mm cylinders
- Mounting Hole Spacing: 15mm (Center-to-center)
- Thread Specifications: M4×0.7 mounting screws
- Weight: 128g ±2%
- Dimensions: 40mm(L) × 20mm(W) × 15mm(H)
- Operating Temperature: -20℃ to 80℃
- Vibration Resistance: ≤49 m/s² (with proper fastening)
- Corrosion Protection: MIL-STD-810G salt spray tested (96hrs)
Precision-engineered mounting bracket designed for secure CPV10M series cylinder fixation in space-constrained environments. Features anti-loosening threaded inserts and CNC-machined alignment grooves for vibration-resistant installations. Includes pre-drilled holes for secondary equipment mounting.
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Semiconductor wafer handling equipment
- Conveyor sorting mechanisms
- Medical device actuation modules
Installation note:
Apply 0.4-0.6N·m torque during screw tightening. Use thread-locking compound
in high-vibration environments. Clean mounting surface with IPA before
installation to ensure optimal thermal conductivity.
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-15F |
