Airtac CPV10M Mounting Base CPV10MJ04-16F
$40.23
Regular price
$47.73
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ04-16F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation guidelines:
Use M16×1.5 screws with recommended torque of 3.5-4.5 N·m.
Apply thread-locking adhesive for permanent installations.
Ensure mounting surface flatness ≤0.05mm/mm².
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-16F Mounting Base Specifications
- Model: CPV10MJ04-16F
- Type: Dedicated mounting base for CPV10M series cylinders
- Compatible Cylinder Bore: Φ10mm
- Mounting Style: Front flange with through-hole fixation
- Material: Aluminum alloy ADC12
- Surface Treatment: Anodized (natural color)
- Thread Specifications: M16×1.5 mounting holes (4 positions)
- Pressure Resistance: ≤1.0 MPa
- Temperature Range: -20℃ to 100℃
- Weight: 0.25 kg ±5%
- Dimensions: 40mm(L) × 40mm(W) × 20mm(H)
- Parallelism Tolerance: ≤0.1mm on mounting surface
- Surface Roughness: Ra 3.2μm (contact surfaces)
Precision-engineered mounting base designed for secure CPV10M cylinder installation in compact automation systems. Features anti-vibration design with evenly distributed stress points and corrosion-resistant anodized finish. Includes self-aligning capability for simplified assembly.
Typical Applications:
- Modular pneumatic assembly systems
- PCB handling robotic arms
- Precision dispensing equipment
- Semiconductor wafer transport mechanisms
- High-cycle packaging line actuators
Installation guidelines:
Use M16×1.5 screws with recommended torque of 3.5-4.5 N·m.
Apply thread-locking adhesive for permanent installations.
Ensure mounting surface flatness ≤0.05mm/mm².
Compatible Accessories:
- CPV10M series cylinders (all stroke lengths)
- ASD10/16 series shock absorbers
- MZW16 series magnetic switches
- Standard M16×1.5 stainless steel fasteners
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-16F |
