Airtac CPV10M Mounting Base CPV10MJ04-17F
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-17F Cylinder Mounting Base Specifications
- Model: CPV10MJ04-17F
- Type: Compact cylinder mounting base (for CPV10M series)
- Compatible cylinder bore: 10mm
- Material: Aluminum alloy (hard anodized surface)
- Mounting style: Side/end plate mounting
- Port thread size: M5×0.8 (standard pneumatic thread)
- Operating pressure range: 0.15–0.8 MPa
- Temperature resistance: -20℃ to 80℃
- Surface hardness: ≥HV300
- Weight: 48g ±2g
- Dimensions: 40mm(L) × 20mm(W) × 15mm(H)
- Mounting hole spacing: 17mm (center-to-center)
- Corrosion protection: Chromate conversion coating
- Vibration resistance: ≤10-55Hz (1.5mm amplitude)
Precision-engineered mounting base designed for CPV10M series mini cylinders, featuring dual-position mounting holes for flexible installation. The hardened anodized surface ensures wear resistance in high-cycle applications (up to 5 million cycles). Includes integrated air passage design for simplified piping.
- Miniature automation assemblies in 3C electronics manufacturing
- Precision pneumatic gripper mounting systems
- Medical device actuation mechanisms
- Packaging machine micro-positioning units
- Semiconductor handling equipment
Installation guidelines:
Use M3 mounting screws with 0.5-0.6Nm torque. Apply thread sealant
(PTFE tape recommended) on port connections. Maintain 0.5mm clearance
between cylinder and base during thermal expansion conditions.
- CPV10M-10~50 cylinders
- APV10 series pivot brackets
- MQS4-01 magnetic sensors
- PFM6-2 flow control valves
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-17F |
