Airtac CPV10M Mounting Base CPV10MJ04-19F
$46.49
Regular price
$53.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV10MJ04-19F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated manifold valve system for compact design, effectively saving space and reducing the need for additional accessories.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
Installation note:
Apply 0.3-0.5Nm torque during valve mounting. Use thread sealant
(PTFE tape excluded) on port connections. Maintain 15mm minimum
clearance below base for tubing access. Thermal cycle test
recommended for applications exceeding 60℃.
2. Centralized air inlet/exhaust ports with streamlined piping layout ensure simplified troubleshooting during malfunctions.
3. Modular design with expandable configuration - allows flexible combination and expansion of solenoid valve units. Compatible with optional blind plates for customized setups.
Category: Solenoid Valve Manifold Bases | Brand: AirTAC | Series: CPV10M Series
AirTAC CPV10MJ04-19F Base Bracket for CPV10M Series Specifications
- Model: CPV10MJ04-19F
- Compatible Valve Series: CPV10M (Direct Mounting)
- Material: Anodized aluminum alloy (AL6063-T5)
- Mounting Type: ISO 15407-1 standard sub-base
- Port Configuration: 4 ports (2 inlet/outlet, 2 exhaust)
- Port Thread Size: M5×0.8 (G1/8 adapter compatible)
- Max Operating Pressure: 1.0 MPa
- Temperature Range: -5℃ to 80℃
- Surface Hardness: HV 120±5 (anodized layer)
- Weight: 185±5g
- Dimensions: 60mm(L) × 34mm(W) × 19mm(H)
- Seal Material: NBR (Nitrile rubber)
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Certification: ISO 9001, RoHS compliant
Precision-engineered mounting base designed for modular pneumatic system integration. Features dual-layer sealing grooves and reinforced mounting bosses for vibration resistance. The diamond-cut surface finish ensures optimal seal contact and prevents air leakage under cyclic loading.
Typical Applications:
- Multi-valve manifold assemblies in packaging lines
- Robotic arm end-effector control clusters
- CNC machine tool pneumatic sequencing units
- Semiconductor handling equipment manifolds
- Automated test bench valve arrays
Installation note:
Apply 0.3-0.5Nm torque during valve mounting. Use thread sealant
(PTFE tape excluded) on port connections. Maintain 15mm minimum
clearance below base for tubing access. Thermal cycle test
recommended for applications exceeding 60℃.
| Property | Property Value |
|---|---|
| sku | CPV10MJ04-19F |
