Airtac CPV15M Manifold Base CPV15M10F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M10F Cylinder Mounting Bracket Technical Details
- Model: CPV15M10F (Compatible with CPV15M series cylinders)
- Material: Aluminum alloy ADC12 with oxidation treatment
- Mounting type: Fixed base with through-hole design
- Bore size compatibility: Ø15mm cylinders
- Surface hardness: HV 120±15
- Weight: 82g ±2g
- Dimensions: 34mm(W) × 25mm(H) × 50mm(L)
- Mounting hole spacing: 20mm center-to-center (M5 thread)
- Temperature resistance: -20°C to 100°C
- Surface finish: Sandblasted anodization (black)
- Static load capacity: 150N vertical / 300N horizontal
- Vibration resistance: 10-55Hz, 1.5mm amplitude
Precision-engineered mounting solution for CPV15M series compact cylinders, featuring anti-corrosion treatment and dual-axis alignment grooves. The through-hole design allows for flexible piping arrangements while maintaining minimal footprint. Includes integrated shock-absorbing rubber pads (SHORE A70) for noise reduction.
- PCB component insertion mechanisms
- Semiconductor wafer handling robots
- Pharmaceutical blister packaging machines
- Automotive window regulator assemblies
- 3D printer extruder positioning systems
Installation note:
Apply 2.0-3.5N·m torque during M5 screw fastening. Use alignment jig
(PN: CPV-AL15) for multi-bracket installations. Lubricate guide slots
with ISO VG32 hydraulic oil monthly in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | CPV15M10F |
