Airtac CPV15M Manifold Base CPV15M11F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M11F Mounting Bracket Specifications
- Model: CPV15M11F
- Compatible Cylinder Series: CPV15M
- Material: Aluminum alloy (6063-T5)
- Surface Treatment: Anodized treatment (natural color)
- Mounting Hole Spacing: 30±0.2mm (horizontal) × 18±0.1mm (vertical)
- Thread Specifications: M5×0.8 (4 holes)
- Load Capacity: Max 25kg static load
- Weight: 98g ±2g
- Dimensions: 52mm(L) × 32mm(W) × 18mm(H)
- Operating Temperature: -20℃ to 150℃
- Vibration Resistance: ≤50m/s² (10-150Hz)
- Corrosion Protection: 96hr salt spray test compliant
Precision-engineered mounting base for CPV15M series compact cylinders, featuring CNC-machined positioning surfaces and anti-loosening thread design. The diamond-shaped groove pattern enhances shock absorption during high-frequency operations. Compatible with both horizontal and vertical mounting orientations.
- Robotic end-effector tooling mounts
- Semiconductor wafer handling systems
- Pharmaceutical capsule sorting mechanisms
- Automated test equipment fixtures
- Precision optical lens positioning stages
Installation note:
Clean mounting surface to Ra3.2 roughness or better.
Apply 0.5-0.8N·m torque during screw tightening.
Use spring washers for vibration-prone environments.
| Property | Property Value |
|---|---|
| sku | CPV15M11F |
