Airtac CPV15M Manifold Base CPV15M12F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M12F Cylinder Mounting Base Specifications
- Model: CPV15M12F
- Type: Compact cylinder mounting base (Side-mount)
- Compatible Cylinder Series: CPV15M (15mm bore size)
- Material: Aluminum alloy ADC12
- Mounting Hole Pattern: 2×M4 threaded holes (center distance 30mm)
- Surface Treatment: Anodized oxidation (natural silver)
- Operating Temperature: -20℃ to 100℃
- Mounting Torque: 1.2 N·m max (for M4 screws)
- Vibration Resistance: 10-55Hz @ 1.5mm amplitude
- Protection Rating: IP54 (when installed with compatible cylinder)
- Weight: 72g ±2g
- Dimensions: 50mm(L) × 34mm(W) × 20mm(H)
- Accessory Compatibility: Works with MISUMI/THK/SMC equivalent rails
Precision-engineered mounting base designed for rigid fixation of CPV15M series compact cylinders in space-constrained automation setups. Features anti-corrosion coating and dual mounting points for enhanced stability during high-cycle operations (up to 1 million cycles). Includes built-in alignment grooves for simplified installation.
- PCB handling robots in electronics assembly
- Precision clamping fixtures for CNC machines
- Linear actuator support in 3D printing systems
- Medical device component positioning stages
- Packaging machine guide rail installations
Installation note:
Apply thread-locking compound (medium strength) on M4 screws.
Maintain 0.5mm clearance between base and cylinder body for thermal expansion.
Use 0.1mm-grade feeler gauge for parallel alignment verification.
| Property | Property Value |
|---|---|
| sku | CPV15M12F |
