Airtac CPV15M Manifold Base CPV15M13F
$37.19
Regular price
$44.69
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV15M13F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated valve manifold design optimizes space utilization and minimizes the need for additional accessories.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
Installation note:
Apply thread-locking compound on mounting screws and verify perpendicularity
(≤0.1mm deviation) using dial indicator during alignment. Avoid overtightening
to prevent base deformation.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M13F Cylinder Mounting Bracket Specifications
- Model: CPV15M13F
- Compatibility: Designed for CPV15M series compact cylinders
- Material: Aluminum alloy (6063-T5)
- Surface treatment: Anodized oxidation (natural color)
- Mounting hole size: M5 through holes (4 places)
- Hole spacing: 30mm (longitudinal) × 20mm (lateral)
- Weight: 0.23kg ±5%
- Dimensions: 52mm(L) × 34mm(W) × 18mm(H)
- Fastener torque: Recommended 1.2-1.5N·m
- Temperature resistance: -20℃ to 100℃
- Surface hardness: HV 80-100
- Corrosion resistance: 96hr salt spray test passed
Precision-machined mounting base for stable cylinder fixation, featuring diamond-knurled anti-slip surfaces and dual-locknut design. The asymmetrical flange structure allows flexible orientation while maintaining minimal profile. Compatible with ISO 6432 mounting standards.
Typical Applications:
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Semiconductor wafer handling equipment
- Medical device actuation mechanisms
- Conveyor sorting gate installations
Installation note:
Apply thread-locking compound on mounting screws and verify perpendicularity
(≤0.1mm deviation) using dial indicator during alignment. Avoid overtightening
to prevent base deformation.
Configuration Tip:
Combine with CPV15M cylinders and MMF15 series magnetic sensors for automated
position feedback systems. Requires periodic inspection (every 500,000 cycles)
for bolt tension maintenance.
| Property | Property Value |
|---|---|
| sku | CPV15M13F |
