Airtac CPV15M Manifold Base CPV15M14F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M14F Cylinder Mounting Base Specifications
- Model: CPV15M14F
- Compatibility: Designed for CPV15M series cylinders
- Material: Aluminum alloy (AL6063-T5)
- Surface treatment: Anodized oxidation (natural color)
- Mounting hole pattern: 14mm pitch (ISO 21287 standard)
- Mounting hole size: M5 threaded (4 holes)
- Base thickness: 8mm ±0.1
- Weight: 128g ±2g
- Dimensions: 60mm(L) × 40mm(W) × 10mm(H)
- Operating temperature: -20℃ to 80℃
- Surface hardness: HV 120-150
- Corrosion resistance: 96hrs salt spray test passed
Precision-machined mounting base featuring vibration-damping design with counterbore holes for secure cylinder fixation. The diamond-knurled surface enhances grip during installation, while the chamfered edges prevent thread damage. Compatible with both horizontal and vertical mounting orientations.
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Conveyor sorting mechanisms
- Semiconductor handling equipment
- Automated packaging line fixtures
Installation protocol:
Use M5×16mm SHCS bolts (Grade 12.9 recommended) with 2.5N·m torque.
Apply thread-locking compound for high-vibration environments.
Clean mounting surface with IPA before assembly.
