Airtac CPV15M Manifold Base CPV15M15F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M15F Cylinder Mounting Bracket Technical Details
- Model: CPV15M15F
- Type: Dedicated mounting base for CPV15M series cylinders
- Compatibility: Specifically designed for CPV15M-□-S-□-B series
- Material: Aluminum alloy ADC12
- Surface treatment: Anodized (natural silver finish)
- Mounting hole spacing: 30±0.1mm (horizontal) × 15±0.1mm (vertical)
- Thread specifications: M5×0.8 mounting threads (4 places)
- Installation torque: 1.2-1.5 Nm (recommended with thread locker)
- Temperature resistance: -10℃ to +80℃ continuous operation
- Surface hardness: HV 120±15 (anodized layer)
- Protection class: IP40 (standard), IP54 optional with gasket
- Weight: 248±5g (including fasteners)
- Dimensions: 56mm(W) × 42mm(D) × 18mm(H)
Precision-machined mounting base featuring vibration-dampening design with 0.01mm positional tolerance. Includes integrated cable management grooves and corrosion-resistant stainless steel M5×12 mounting screws (JIS B1177 compliant). Optimized for high-cycle applications with anti-loosening thread design.
- Modular pneumatic assembly systems requiring quick cylinder replacement
- High-frequency pick-and-place robots (≥60 cycles/min)
- Cleanroom-compatible semiconductor manufacturing equipment
- Multi-axis positioning stages in automated optical inspection (AOI) systems
- Food processing machinery requiring washdown-resistant components
Installation protocol:
Apply 0.1-0.2ml of medium-strength thread locker (Loctite 243 equivalent)
before torqueing. Use 0.05mm shim washers when mounting on uneven surfaces.
Re-torque after 50 operating hours.
| Property | Property Value |
|---|---|
| sku | CPV15M15F |
