Airtac CPV15M Manifold Base CPV15M16F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M16F Cylinder Mounting Base Specifications
- Model: CPV15M16F (Compatible with CPV15M series cylinders)
- Material: Aluminum alloy with black anodized finish
- Mounting type: Dual-side fixed flange
- Bore size compatibility: Ø15mm cylinders
- Thread specifications: M6×1.0 mounting holes (4 places)
- Surface hardness: HV0.3≥150
- Weight: 82±3g
- Dimensions: 42mm(L) × 28mm(W) × 16mm(H)
- Center distance: 16mm between mounting holes
- Temperature range: -20℃ to 100℃
- Surface treatment: Sandblasting + Anodizing
- Corrosion resistance: 96hr salt spray test passed
Precision-machined mounting base designed for secure CPV15M series cylinder fixation in compact automation systems. Features anti-vibration design with 4-point M6 fastening and CNC-milled alignment grooves. Includes built-in shock absorption through elastic deformation design at contact surfaces.
- PCB component insertion machines
- Semiconductor wafer handling robots
- Precision dispensing equipment
- Optical lens positioning systems
- High-frequency pick-and-place units
Installation note:
Apply 0.5-0.8N·m torque during screw tightening. Use M6 spring washers
for vibration-prone environments. Lubricate contact surfaces with
silicone grease (ASG-46T recommended) before assembly.
