Airtac CPV15M Manifold Base CPV15M17F
$46.49
Regular price
$53.99
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV15M17F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated valve manifold design optimizes space utilization and minimizes the need for additional accessories.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
Installation protocol:
Apply 0.5-0.8 N·m torque during screw fastening. Use thread sealant
on ports exceeding 0.6 MPa. Align with cylinder using guide pins
before final tightening.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M17F Mounting Bracket Technical Details
- Model: CPV15M17F
- Compatible Series: Designed for CPV15M compact cylinders
- Mounting Pattern: ISO 6432 standard (8mm bore spacing)
- Port Thread: Dual M5×0.8 pneumatic ports (front/rear)
- Material: Aluminum alloy ADC12 with hard anodized finish
- Surface Hardness: ≥HV150
- Operating Pressure: 0.1–1.0 MPa
- Temperature Range: -20℃ to 80℃
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Weight: 0.25 kg ±5%
- Dimensions: 17mm(W) × 17mm(D) × 25mm(H)
- Mounting Screws: M4×8 stainless steel (included)
- Vibration Resistance: ≤20 m/s² (ISO 10816-3)
Precision-machined mounting base enabling stable CPV15M cylinder integration in modular pneumatic systems. Features dual-port flow paths for bidirectional control and anti-corrosion coating for harsh environments. Includes integrated O-ring grooves for leak-proof connections.
Primary Applications:
- Modular assembly in robotic gripper configurations
- Precision positioning stages for optical equipment
- Compact pneumatic clamping systems
- Laboratory automation tool changers
- Medical device actuation modules
Installation protocol:
Apply 0.5-0.8 N·m torque during screw fastening. Use thread sealant
on ports exceeding 0.6 MPa. Align with cylinder using guide pins
before final tightening.
Complementary Components:
Pairs with AS2201F solenoid valves and APV10 speed controllers.
Requires 3mm hex key for installation (not included).
