Airtac CPV15M Manifold Base CPV15M20F
$53.47
Regular price
$60.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV15M20F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated valve manifold design optimizes space utilization and minimizes the need for additional accessories.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
Installation note:
Apply 0.3-0.5Nm torque during screw tightening. Use shim washers when mounting
on uneven surfaces (>0.2mm deviation). Compatible with ISO 6432 mounting standards.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M20F Cylinder Mounting Base Specifications
- Model: CPV15M20F
- Type: Compact cylinder mounting base (side-mount)
- Compatible Series: CPV15M pneumatic cylinders
- Material: Aluminum alloy ADC12
- Surface Treatment: Anodized (natural aluminum color)
- Mounting Hole Spacing: 20mm (center-to-center)
- Thread Specifications: M4 mounting screws (included)
- Operating Temperature: -20℃ to 80℃
- Storage Temperature: -30℃ to 90℃
- Weight: 78g ±2g
- Dimensions: 42mm(L) × 20mm(W) × 15mm(H)
- Vibration Resistance: ≤10Hz with 1.5mm amplitude
- Shock Resistance: 98m/s² max (3-axis direction)
Precision-engineered mounting base designed for secure CPV15M series cylinder fixation in space-constrained environments. Features anti-corrosion anodized finish and optimized load distribution design. Includes pre-installed thread-locking adhesive on screws for vibration resistance.
Typical Applications:
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Conveyor belt sorting mechanisms
- Semiconductor handling equipment
- Medical device actuation systems
Installation note:
Apply 0.3-0.5Nm torque during screw tightening. Use shim washers when mounting
on uneven surfaces (>0.2mm deviation). Compatible with ISO 6432 mounting standards.
Optimized Pairing:
- Best performance with CPV15M-10A to CPV15M-50A cylinders
- Requires M4×0.7mm pitch screws (Grade 8.8 or higher recommended)
- For vertical mounting: Add secondary safety bracket when acceleration >0.5G
| Property | Property Value |
|---|---|
| sku | CPV15M20F |
