Airtac CPV15M Manifold Base CPV15M2F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M2F Cylinder Mounting Base Specifications
- Model: CPV15M2F (Compatible with CPV15M series cylinders)
- Material: Aluminum alloy ADC12 with anodized surface treatment
- Mounting type: Swivel base with dual-axis adjustment
- Bore size compatibility: ø15mm cylinders
- Mounting hole spacing: 30mm ±0.1mm (center-to-center)
- Thread specifications: M6×1.0 mounting threads (4 places)
- Surface hardness: HV 120±15
- Operating temperature: -20℃ to 80℃
- Static load capacity: 180N (maximum)
- Dynamic load capacity: 90N (at 0.5MPa)
- Weight: 0.28kg ±5%
- Dimensions: 56mm(L) × 42mm(W) × 22mm(H)
- Surface roughness: Ra ≤3.2μm (contact surfaces)
Precision-engineered swivel mounting base designed for angular adjustment compensation in pneumatic cylinder installations. Features anti-corrosion coating and wear-resistant pivot points, with laser-etched alignment markers for simplified positioning. Includes integrated vibration dampening channels to reduce harmonic resonance.
- Robotic arm end-effector mounting systems
- Conveyor line pusher mechanisms
- Semiconductor wafer handling equipment
- Automated door locking actuators
- Textile machinery tension control units
Installation note:
Apply 2-3Nm torque during screw fastening. Use shim washers when mounting
on uneven surfaces (>0.2mm deviation). Lubricate pivot points with ISO VG32
hydraulic oil before initial operation.
Compatibility notice: Requires matching with CPV15M series cylinder body (CPV15M1S/CPV15M2S). Not compatible with ISO 6432 standard cylinders without adapter kit CPV-ADP15.
| Property | Property Value |
|---|---|
| sku | CPV15M2F |
