Airtac CPV15M Manifold Base CPV15M3F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M3F Cylinder Mounting Bracket Detailed Specifications
- Model: CPV15M3F (Compatible with CPV15M series cylinders)
- Type: Precision-machined mounting base with integrated alignment pins
- Material: 6063-T5 aluminum alloy
- Mounting hole spacing: 30±0.1mm (horizontal) × 15±0.05mm (vertical)
- Thread specifications: M4×0.7 deep 8mm (4 mounting points)
- Surface treatment: Anodized treatment (black) with 15-20μm thickness
- Weight: 82g ±2g
- Dimensions: 56mm(L) × 32mm(W) × 12.5mm(H)
- Operating temperature: -20℃ to 120℃ (static load)
- Vibration resistance: ≤15Hz frequency, 1.5mm amplitude
- Load capacity: Max 250N static lateral force
CNC-machined mounting solution designed for precision alignment of CPV15M series compact cylinders. Features hardened stainless steel alignment pins (HRC 45-50) and anti-loosening thread design. The anodized surface provides exceptional corrosion resistance in humid environments while maintaining electrical insulation properties (withstand voltage: 500V AC).
- Modular pneumatic assembly systems requiring repeatable positioning
- High-cycle automation equipment (e.g., IC chip handlers)
- Cleanroom-compatible machinery in semiconductor manufacturing
- Multi-axis actuator configurations needing vibration damping
- Food processing equipment requiring washdown-ready components
Installation protocol:
Apply 0.3-0.5Nm torque during screw fastening. Use shim washers when mounting
on surfaces with roughness >Ra3.2. Clean mating surfaces with IPA before assembly
for optimal vibration resistance.
| Property | Property Value |
|---|---|
| sku | CPV15M3F |
