Airtac CPV15M Manifold Base CPV15M4F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M4F Cylinder Mounting Bracket Technical Details
- Model: CPV15M4F (Compatible with CPV15M series cylinders)
- Material: Anodized aluminum alloy 6063-T5
- Mounting type: Side-mount with dual reinforcement ribs
- Bore size compatibility: Ø15mm cylinders
- Hole spacing: 25mm center-to-center (M4 threaded)
- Thread specifications: M4×0.7 mounting screws (4 places)
- Surface hardness: HV 120±15 (hard anodized finish)
- Weight: 82g ±2g (including fasteners)
- Dimensions: 48mm(L) × 32mm(W) × 18mm(H)
- Temperature range: -20℃ to 150℃ (intermittent peak 180℃)
- Surface treatment: Black sandblasted anodization
- Corrosion resistance: 96hr salt spray test passed
- Vibration resistance: 10-2000Hz, 15G acceleration
Precision-engineered mounting base for linear actuators, featuring anti-rotation design with integrated alignment pins. The asymmetrical flange structure provides 25% greater torsional rigidity compared to standard brackets. Includes stainless steel M4×12 mounting screws with Loctite® pre-applied thread locker.
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Conveyor belt sorting mechanisms
- Semiconductor wafer handling equipment
- Food-grade packaging machinery (FDA-compliant version available)
Installation protocol:
Apply 0.3-0.5Nm torque during screw tightening. Use shim washers when mounting
on surfaces with roughness above Ra3.2. Compatible with ISO 6432 mounting grooves.
| Property | Property Value |
|---|---|
| sku | CPV15M4F |
