Airtac CPV15M Manifold Base CPV15M5F
$18.57
Regular price
$26.07
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CPV15M5F
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Integrated valve manifold design optimizes space utilization and minimizes the need for additional accessories.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
Installation protocol:
Apply 0.3-0.5Nm torque during screw fastening using M5×8mm stainless steel screws.
Use Shim Kit CPV-ADJ15 when compensating for surface irregularities >0.1mm.
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M5F Mounting Base Specifications
- Model: CPV15M5F
- Type: Dedicated mounting base for CPV15M series cylinders
- Material: High-strength aluminum alloy (A6063-T5)
- Mounting Style: Horizontal/vertical dual-orientation flange mount
- Compatible Cylinder Bore: ø15mm
- Mounting Hole Pattern: 30mm × 18mm rectangular array
- Thread Specifications: M5×0.8 mounting screws (4 places)
- Surface Treatment: Anodized oxidation (black) with anti-scratch coating
- Weight: 82g ±2g
- Dimensions: 48mm(L) × 32mm(W) × 12.5mm(H)
- Operating Temperature: -20℃ to 80℃
- Surface Hardness: HV 80-100
- Vibration Resistance: 10-55Hz, 1.5mm amplitude
- Protection Rating: IP54 (standard configuration)
Precision-engineered mounting base featuring CNC-machined alignment grooves and reinforced load-bearing surfaces. The diamond-knurled bottom surface enhances friction stability during high-frequency operations. Includes integrated cable routing channels for sensor wiring management.
Typical Applications:
- Modular pneumatic assembly systems
- SCARA robot end-effector mounting
- Precision dispensing equipment
- Semiconductor wafer handling mechanisms
- Automated test fixture positioning
Installation protocol:
Apply 0.3-0.5Nm torque during screw fastening using M5×8mm stainless steel screws.
Use Shim Kit CPV-ADJ15 when compensating for surface irregularities >0.1mm.
| Property | Property Value |
|---|---|
| sku | CPV15M5F |
