Airtac CPV15M Manifold Base CPV15M6F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M6F Mounting Bracket for CPV15M Series
- Model: CPV15M6F
- Compatible Series: CPV15M solenoid valves
- Mounting Type: Panel-mounted (DIN rail adaptable)
- Material: Aluminum alloy with anodized finish
- Port Thread Size: M5 × 0.8 or 1/8" NPT (configurable)
- Max Operating Pressure: 1.0 MPa
- Temperature Resistance: -20℃ to 70℃
- Surface Hardness: HV 400±50
- Weight: ~120g (excluding valve)
- Dimensions: 25mm(W) × 25mm(D) × 15mm(H)
- Mounting Hole Spacing: 18mm ±0.2 (center-to-center)
- Surface Roughness: Ra ≤3.2μm
- Corrosion Resistance: 96hr salt spray test compliant
Precision-engineered mounting base featuring vibration-damped installation and multi-orientation capability (horizontal/vertical). The hexagonal cavity design ensures secure valve seating with O-ring compression, while the through-hole structure allows for concealed tubing routing. Includes integrated shock absorption pads for noise reduction in high-cycle applications.
- Modular pneumatic control panels
- Robotic end-effector installations
- CNC machine tool pneumatic clusters
- Food processing equipment (FDA-compliant grease option)
- Mobile hydraulic hybrid systems
Installation protocol:
Apply 0.5-0.8Nm torque during screw fastening. Use included shim washers
when mounting on surfaces with >0.5mm flatness deviation. For vertical
installations, orient pressure port downward to prevent particulate accumulation.
| Property | Property Value |
|---|---|
| sku | CPV15M6F |
