Airtac CPV15M Manifold Base CPV15M8F
2. Unified air inlet/exhaust ports with centralized wiring facilitate efficient system maintenance and troubleshooting.
3. Modular design offers flexible configuration and high expandability for multiple solenoid valve connections, compatible with optional blanking plates.
Category: Solenoid Valve Base | Brand: AirTAC | Series: CPV15M Series
AirTAC CPV15M8F Cylinder Mounting Base Specifications
- Model: CPV15M8F (Compatible with CPV15M series cylinders)
- Material: Aluminum alloy (A6061) with hard anodized finish
- Mounting type: Side mounting base with dual rail compatibility
- Port size: M5x0.8 (Standard) / Optional NPT1/8 adapters
- Bore compatibility: Ø15mm cylinders
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 100℃ (static) / -10℃ to 80℃ (dynamic)
- Surface hardness: HV 120±5
- Weight: 220±5g
- Dimensions: 78mm(L) × 34mm(W) × 42mm(H)
- Mounting hole spacing: 60mm center-to-center
- Surface roughness: Ra 1.6μm (contact surfaces)
- Seal material: NBR rubber (Standard) / Optional FKM
Precision-engineered mounting base featuring dual T-slot rails for flexible cylinder positioning. The staggered bolt pattern ensures vibration resistance in high-cycle applications. Anodized surface provides corrosion resistance for humid environments. Includes integrated cable management channels.
- Modular pneumatic assembly systems
- Pick-and-place robot end effectors
- Semiconductor wafer handling equipment
- Pharmaceutical packaging lines
- Automated test fixture positioning
Installation note:
Use vibration-proof screws (M6x12 recommended) with 2.5-3.0 N·m torque.
Apply silicone-free lubricant on rail surfaces before cylinder insertion.
Maintain 0.5mm clearance between adjacent components for thermal expansion.
