Airtac CS1 Proximity Sensor CS1-F
This cylinder-mounted sensing solution features optimized magnetic responsiveness and durable construction, specifically engineered for pneumatic cylinder position detection in industrial automation applications. The CS1 series ensures reliable signal transmission and extended service life in demanding operating conditions.
Category: Cylinder Sensor | Brand: AIRTAC | Series: CS1
AirTAC CS1-F Proximity Sensor Specifications
- Model: CS1-F
- Type: Inductive proximity sensor (shielded)
- Sensing distance: 1.5mm ±10%
- Output configuration: NPN normally open (NO)
- Operating voltage: 6-36V DC
- Current consumption: ≤15mA
- Response frequency: 500Hz
- Hysteresis: ≤15% of sensing distance
- Housing material: Nickel-plated brass
- Temperature range: -25℃ to +70℃
- Connection type: 2m PVC cable (M8 connector optional)
- Protection rating: IP67 (IEC standard)
- Weight: 25g ±2g
- Dimensions: 18mm(D) × 34mm(L) × 10mm(W)
High-precision inductive sensor with temperature-stable oscillation circuit, featuring short-circuit and reverse polarity protection. The shielded design enables flush mounting in metal surfaces. LED status indicator provides visual operation feedback. Meets EMC Directive 2014/30/EU requirements.
- Position verification in pneumatic cylinder end stops
- Material presence detection in conveyor systems
- Rotational speed monitoring of machinery components
- Safety interlock systems in automated assembly lines
- Elevator door position sensing
- Packaging machine component alignment
Installation guidelines:
Maintain 3x sensor diameter clearance from adjacent metal objects.
For optimal performance, clean sensing face regularly and avoid
metal particle accumulation. Use M4 mounting screws with 0.4-0.5Nm torque.
- Leakage current: <10μA
- Voltage drop: <2.5V
- Inrush current: <20mA
- Repeat accuracy: ±0.02mm
| Property | Property Value |
|---|---|
| sku | CS1-F |
| Specification | Type F |
