Airtac CS1A Reed Sensor CS1A050
2. This deceptively simple design provides robust circuit control for diverse industrial and commercial applications, ensuring reliable switching performance in electrical systems.
AirTAC CS1A Reed Switch Sensor CS1A050 Technical Details
- Model: CS1A050
- Type: Magnetic proximity sensor (Reed switch)
- Output configuration: NPN/PNP NO/NC (configurable)
- Voltage range: DC10-30V (±10%)
- Current consumption: ≤15mA
- Sensing distance: 0-50mm (adjustable)
- Response frequency: ≤100Hz
- Protection rating: IP67 (IEC standard)
- Housing material: PA66+GF25% (UL94 V-0)
- Contact capacity: 200mA max
- Temperature range: -25℃ to +70℃
- Indication: Dual-color LED (Red/Green)
- Weight: 32g ±1g
- Dimensions: 18.5mm(W) × 40mm(H) × 8.5mm(D)
- Cable length: 2m standard (PUR jacket)
- Certification: CE, RoHS, REACH
High-precision magnetic position detector with configurable logic outputs, featuring overvoltage and reverse polarity protection. The hermetically sealed reed contacts ensure reliable operation in contaminated environments. Compact design enables direct mounting on ISO standard pneumatic cylinders.
- Pneumatic cylinder position feedback in automation lines
- Safety interlock systems for machinery guards
- Material handling equipment limit detection
- Elevator door position monitoring
- Packaging machine cycle counting
- Hydraulic piston stroke verification
Installation guidelines:
Mount parallel to cylinder axis with 0.5-1mm gap from magnetic piston.
Use shielded cable for EMI environments. Maximum lateral offset ≤3mm.
Avoid mounting near high-current cables (>10A).
