Airtac CS1A Reed Sensor CS1AXC12
2. This deceptively simple design provides robust circuit control for diverse industrial and commercial applications, ensuring reliable switching performance in electrical systems.
AirTAC CS1A Reed Sensor CS1AXC12 Technical Specifications
- Model: CS1AXC12
- Type: Cylindrical magnetic proximity sensor (Reed switch)
- Sensing method: Non-contact magnetic actuation
- Output configuration: NPN normally open (NO)
- Operating voltage: 5-30V DC (±10%)
- Current consumption: ≤15mA
- Load current: ≤200mA
- Response frequency: ≤100Hz
- Hysteresis: ≤15% of sensing distance
- Protection rating: IP67 (dust/water resistant)
- Housing material: Nickel-plated brass
- Operating temperature: -25℃ to +80℃
- Storage temperature: -40℃ to +85℃
- Weight: 28g ±2g
- Dimensions: Ø12mm × 50mm (L)
- Cable length: 2m standard (4-core shielded)
- Actuation distance: 15mm (with standard magnet)
Compact cylindrical magnetic sensor designed for precision position detection in harsh environments. Features reverse polarity protection and surge suppression, with LED status indication. The brass construction ensures vibration resistance and long-term stability in industrial applications.
- Hydraulic cylinder position feedback
- Automated conveyor belt systems
- Robotic arm end-effector detection
- Injection molding machine safety interlocks
- Elevator door position verification
Installation guidelines:
Maintain ≤0.5mm radial alignment tolerance between sensor and actuator magnet.
Avoid metal shavings accumulation near sensing area. Use M12 mounting nut with
18-22N·m torque. Cable routing should prevent sharp bends (min. bend radius 25mm).
| Property | Property Value |
|---|---|
| sku | CS1AXC12 |
