Airtac CS1F Reed Sensor CS1F100
$14.85
Regular price
$22.35
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
CS1F100
Product type:
Tags:
Collections:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
The CS1F Reed Sensor operates by utilizing permanent magnets or electromagnets to generate a magnetic field that activates/deactivates the encapsulated reed switch mechanism.
This elegantly simple design delivers dependable circuit control across a wide range of industrial and commercial equipment applications, demonstrating exceptional reliability in electrical switching operations.
Installation guidelines:
Mount sensor parallel to cylinder axis with 2-3mm air gap from magnet.
Use anti-vibration shims in high-frequency applications (>50Hz).
For optimal performance, keep ferrous metal debris clearance ≥5mm.
This elegantly simple design delivers dependable circuit control across a wide range of industrial and commercial equipment applications, demonstrating exceptional reliability in electrical switching operations.
AirTAC CS1F100 Reed Sensor Technical Specifications
- Model: CS1F100
- Type: Magnetic reed proximity sensor (non-contact)
- Operating voltage: DC10-30V (±10% ripple)
- Output type: NPN normally open (NO) or PNP configurable
- Sensing distance: 0-25mm (adjustable)
- Housing material: Glass-filled PBT with nickel-plated brass fittings
- Protection rating: IP67 (dust/water resistant)
- Temperature range: -25℃ to +80℃
- Connection type: 2m PVC cable (M8 connector optional)
- Cable specs: 4-core shielded 0.2mm² (28AWG)
- Response frequency: ≤100Hz
- Load current: ≤200mA
- Hysteresis: ≤15% of sensing distance
- Weight: 85g ±3g
- Dimensions: 18mm(W) × 40mm(H) × 8.5mm(D)
Compact magnetic proximity switch designed for cylinder position detection in pneumatic systems. Features dual-color LED status indication (red/green) and reverse polarity protection. The wear-free design ensures >10 million operations at rated load.
Key Applications:
- Industrial automation cylinder position feedback
- Packaging machine stroke limit detection
- Injection molding machine clamp position sensing
- Elevator door position monitoring systems
- AGV docking alignment verification
Installation guidelines:
Mount sensor parallel to cylinder axis with 2-3mm air gap from magnet.
Use anti-vibration shims in high-frequency applications (>50Hz).
For optimal performance, keep ferrous metal debris clearance ≥5mm.
Wiring Details:
- Brown wire: +V (DC10-30V)
- Blue wire: 0V
- Black wire: Signal output (NPN)
- White wire: Diagnostic feedback (optional)
| Property | Property Value |
|---|---|
| sku | CS1F100 |
